Open hole logging services

Open hole logging technology is an important method for underground oil and gas exploration. It involves using instruments that reflect various physical properties such as heat, sound, electricity, light, magnetism, and nuclear radioactivity to measure the different physical characteristics of formations in a drilling well. By processing and interpreting this data based on their respective physical principles and interrelationships, it helps identify the porosity, permeability, fluid properties, and distribution of underground rocks. This information is crucial for discovering oil and gas reservoirs, assessing reserves, and predicting production rates. Our company specializes in conventional logging services for vertical, directional, and horizontal wells, as well as special logging services (dielectric scanning logging, elemental capture logging, nuclear magnetic logging, cross-dipole acoustic logging, micro-resistivity imaging logging, pressure-controlled closed chamber coring), and wellbore quality logging operations and data processing and interpretation.

Introduction
Components
Features

The ST9000 imaging logging system is primarily used for logging services in open hole and cased hole wells. It integrates advanced digital data acquisition systems, multitasking computer processing, and imaging technology to significantly enhance the safety and reliability of the system.

ST9000 Complete Imaging Logging System	ST9000 Surface Equipment	Surface System	Surface Data Acquisition System
			Winch Face Plate
			Depth Sensor
		Detection System	Surface Detection System
		Detection System	Resistivity Tester
	ST9000 Downhole Equipment	Conventional Instrument Series	Telemetry, Inclination and Directional Integrated Instrument
			Natural Gamma Ray Spectroscopy Logging Tool
			Continuous Inclinometer Circuit
			Digital Sonic General-Purpose Electronic Short Tool
			High-Resolution Digital Sonic Logging Tool
			Compensated Neutron Logging Tool
			Formation Density Logging Tool
			Conversion Short Tool
			Dual Laterolog Logging Tool
			Micro-Spherical Caliper Logging Tool
			Constant Power Dual Laterolog Logging Tool
		Imaging Instrument Series	High-Resolution Array Induction Logging Tool
		Imaging Instrument Series	Cross-Dipole Array Sonic Logging Tool
			Four-Arm Caliper Logging Tool
			Flexible Short Tool
			Insulated Short Tool
			Magnetic Casing Collar Locator（CCL）
			Orienting Tool
			Three Parameters Logging Tool
			Rotating Short Tool

Detection System

Conventional Instruments

Excellent interchangeability: The system's communication protocols, measurement accuracy, mechanical interfaces, and software operations are fully compatible with the ECLIPS-5700 logging system. Any downhole tools corresponding to the ECLIPS-5700 system can be completely interchangeable, meeting or exceeding the performance of the 5700 logging instruments.
Downhole tool joints and circuit housings are made of titanium alloy, while the threads are made of aluminum bronze, making the instrument lightweight, non-sticky, and reducing operator fatigue.
Instrument length reduced by 5.06 meters, enhancing safety.
Utilization of 296℃ soldering improves instrument reliability.
Product designed for bare frame operation at 175℃, pressure-resistant up to 140MPa, allowing for extended downhole operations, especially suitable for horizontal wells and long-term continuous logging compared to the original ECLIPS-5700 logging tool.
Available in various series: Φ70 small diameter, Φ89-175℃, Φ89-200℃-170MPa.
